The ideal plate for your protein crystallization applications.

ARI has developed the ideal protein crystallization plate: the INTELLI-PLATE®. All versions of the INTELLI-PLATE® have the SBS microplate footprint and standard well spacing and are ideal for manual or automated processing. The complete INTELLI-PLATE product line, both full height and low profile, is available with barcode labels printed to your specifications. Bar codes are printed and applied in our production facility, so your orders will be shipped promptly.

The INTELLI-PLATE 96® comes in both 2 and 3 well versions as well as a low profile version. All plates are promptly available with preprinted bar code labels printed to your specifications.

INTELLI-PLATE 96

The INTELLI-PLATE 96-3 Low Volume Reservoir features three 1.0μL reaction wells and a 100μL screen reservoir. Each identical well features a round bottom for easy crystal harvesting and is arranged in an 8 x 12 array. This plate has low birefringence. This plate is also available with a low profile height and compatible with the CrystalMation™ system.

The INTELLI-PLATE 96-2 Low Volume Reservoir is a 96 well sitting drop vapor diffusion crystallography plate. Each plate is arranged in an 8 x 12 array. Each array location has a reservoir well and two sample wells – each of different sizes. The maximum fill volume of each reservoir well is 100μl, with 4µl and 10µl for the two sample wells. This plate has low birefringence. This plate is also available with a low profile height and compatible with the CrystalMation™ system.

INTELLI-PLATE 48

The INTELLI-PLATE 48-2 is a 48 well sitting drop vapor diffusion crystallography plate for optimization. Each plate is arranged in a 6 x 8 array. Each of the 48 array locations has a reservoir well and two sample wells – one round and one elongated. The maximum fill volume of each reservoir well is 500µl, with 4µl for the round sample well and 20µl for the elongated sample well.

The INTELLI-PLATE 48-3 is a 48 well sitting drop vapor diffusion crystallography plate for screening. Each plate is arranged as a 6 x 8 array. Each of the 48 array locations has a reservoir well and three identical sample wells. The maximum fill volume of each reservoir well is 500μl, with 4μl for each of the three sample wells.

​INTELLI-PLATE 24

The INTELLI-PLATE 48-2 is a 48 well sitting drop vapor diffusion crystallography plate for optimization. Each plate is arranged in a 6 x 8 array. Each of the 48 array locations has a reservoir well and two sample wells – one round and one elongated. The maximum fill volume of each reservoir well is 500μl, with 4μl for the round sample well and 20ul for the elongated sample well.

The INTELLI-PLATE 48-3 is a 48 well sitting drop vapor diffusion crystallography plate for screening. Each plate is arranged as a 6 x 8 array. Each of the 48 array locations has a reservoir well and three identical sample wells. The maximum fill volume of each reservoir well is 500μl, with 4μl for each of the three sample wells.
